Shimano HB-TC500-15-B Centerlock Front Hub

HB-TC500-15-B is a high-performance front hub for mountain and touring bikes with center lock brake rotors and 15 x 110 mm Boost width at the front. Shimano recommends them as a supplement for 10- to 12-speed drivetrains at SLX and Deore level. However, it also fits CUES 9-speed, 10-speed and 11-speed drivetrains or 8-speed setups at Acera and Altus level. The hub is approved for use on e-bikes and is recommended by Shimano for the EP8 and EP6 series. It features an appropriate ratio between weight and stiffness as well as solid cartridge bearings. A double sealing system extends the service life. The hub body is made of lightweight aluminium with an anodised finish. Use this hub for spoke diameters of 2 or 2.3 mm.

Features
Performance: reliable performance with stiff, lightweight E-Thru design
Sealing: double sealed
Rotor mounting: easy installation with toothing and lockring (lockring not included)
Spoke compatibility: 13G and 14G spokes
Offset: 5.3 mm
Flange diameter: 52.8 mm (both sides)
Hub shell: anodised

Specifications
Performance: reliable performance with stiff, lightweight E-Thru design
Sealing: double sealed
Rotor mounting: easy installation with toothing and lockring (lockring not included)
Spoke compatibility: 13G and 14G spokes
Offset: 5.3 mm
Flange diameter: 52.8 mm (both sides)
Hub shell: anodised

Mfr Claimed Weight
TBC
